2TB HDD DVR 4CH 4G GPS WIFI MDVR Vehicle Camera Remote Monitor Solution for School Bus

Name: 2TB HDD DVR 4CH 4G GPS WIFI MDVR Vehicle Camera Remote Monitor Solution for School Bus
Brand: Richmor
Price: 225.00 USD

Buy cheap 2TB HDD DVR 4CH 4G GPS WIFI MDVR Vehicle Camera Remote Monitor Solution for School Bus product

Place of Origin : Guangdong, China

Brand Name : Richmor

Model Number : RCM-MDR7204-001

Resolution : 1080P/720P/D1/HD1/CIF

TV system : PAL or NTSC

Compression : H.264 4channel

Certification : CE FCC RoHS

Video input : 8CH , 4CH

storage : Up to 2TBHDD & 128 SD card

Monitoring Device : PC/Mobile Phone

Feature : 4G GPS WIFI

IP Camera Input : 4CH , 1CH ,8CH

Keyword : Hybrid DVR

Packaging Details : Standard giftbox (Richmor/Neutral)

Price : $225.00/units 1-49 units

Contact Now

2TB HDD DVR 4CH 4G GPS WIFI MDVR Vehicle Camera Remote Monitor Solution for School Bus

Richmor mobile dvr 4 channel ahd dvr

school bus mobile dvr

PRODUCT DESCRIPTION
Resolution	4CH 1080P AHD Full real-time recording
Module	G-Sensor built in, GPS /3G/4G /WIFI (5.8G or 2.4G )Optional
Storage	*Support 12TB HDD + 1128GB SD cards*
Alarm I/O	8CH Alarm input,2CH Alarm output
ACC Delay	10 seconds delay pow-off for data protection
Voltage	8V-36V Wide range voltage power supply

2TB HDD DVR 4CH 4G GPS WIFI MDVR Vehicle Camera Remote Monitor Solution for School Bus

Detailed specification was listed as follows for checking, please contact us we'll do our best to cooperate.

Item		Parameter
OS		Linux
Language		Chinese/English/Others(can be customized)
Video Compression		H.264
Operation Interface		OSD menu
	Video Input	Support 4 CH Full real-time AHD1080P
Video Record System	Video Output	1 CH composite video output
	Display	1/2/4 CH full screen
	Signal system	PAL/NTSC (PAL @100Frame, NTSC@120 Frame
	Resolution	Support 4 CH Full real-time AHD 720P
	Record Format	Synchronized A/V recording
Audio	Audio Input	4 CH
	Audio Output	2 CH
	Compression	G.726
Alarm	Input	9 CH
	Output	2 CH
Storage		Support 2.5" 2TB HDD & 128GB SD Card
Communication Port		3CH RS232 / 2CH RS485
G-sensor		Built in, support 3 Axis Motion Detection with user set ranges , for X,Y and Z coordinates
Wireless communications		GPS /3G /4G /WIFI optional
GPS		GPS /Glonass
Video Playback	Video Search	Search video by Record Time/ Type etc
	Playback	A/V,GPS,Map view,Speed,G-sensor,video files available for playback on PC.
	CMS	Wireless(require Wi-Fi or cellular), real-time monitoring .GPS and alarm etc
Operating Voltage	Voltage Input	8V ~ 36V DC
	Voltage Output	12V @1.2A 4 CH, with IR	12V @0.9A 2 CH, with IR
	Power -off Protection	All video information can be saved automatically when the power cut off, and make sure that all the files can not be damaged
	UPS	External UPS battery optional, support 24 hours monitoring
Other	Operation Temperature	-20℃ ~ + 50℃
	Humidity	20% ~ 80%
	Dimension	17660187mm
	Weight	1.8KG

2TB HDD DVR 4CH 4G GPS WIFI MDVR Vehicle Camera Remote Monitor Solution for School Bus

RCM-MDR7104 Accessories
Standard
*Key1**	*CD1**
*Remote controller1**	*6PIN power cable1**
*16PIN output1**	*24PIN alarm cable1**
*VGA switching cable(6 pin)1**	*USB cable1**
*Audio & Video 4**
Optional
4G Antenna	WIFI Antenna
GPS Antenna

2TB HDD DVR 4CH 4G GPS WIFI MDVR Vehicle Camera Remote Monitor Solution for School Bus
